A2052 – 50mm Double Dynamic Block | High-Performance Sailing Block for Keelboats & Catamarans
The A2052 is a high performing ball bearing block, designed to eliminate friction and allow rope to run at great speeds.
Ideal for use on Keelboats and Catamarans for a range of applications from jib sheet to mainsheet systems, to backstay tensioning systems and everything in between. The 50mm double is a great choice for systems which require a larger purchase system with minimal friction.
Perfect for keelboats and catamarans, this versatile block suits a wide range of applications — from jib sheet to mainsheet systems and everything in between.
Patented Bearing System – Dynamic Block Technology Dynamic Blocks feature an exclusive patented bearing system using twin rows of stainless-steel ball bearings running on a stainless-steel rail. This delivers superior load-carrying capacity and outstanding longevity compared to conventional bearing systems on the market.
Swivel Lock – Effortless Orientation Control The block head incorporates a swivel lock mechanism: simply turn the locking screw to either fix the swivel at 90-degree orientations or release it for full free-spinning rotation, giving you complete flexibility for any rigging configuration.
Becket – Lightweight Design & Versatile Attachment The large central becket hole reduces the overall weight of the block while providing a rope-friendly attachment point. Ideal as a tie-off point in cascade systems for smooth and reliable load distribution.
Data sheet
- Fitting type
- Poulie dynamic
- Rope diameter ( mm )
- 10
- MWL - Max Working Load ( Kg )
- 450
- Weight ( g )
- 148
- Length ( mm )
- 100
- Sheave diameter ( mm )
- 50
- Block specificity
- Shackle on swivel
- Block type
- Double
- Sheave Type
- Resin
- Diamètre axe de manille ( mm )
- 4
- Breaking Load ( Kg )
- 950
Specific References
- ean13
- 5055276509066
Download
A2052 - - DYNAMIC double block - Sheave Ø 50mm
