CONSTRICTOR® KIT 6MM

LIGHTWEIGHT BASE FOR CONSTRICTOR® TEXTILE INSERT

Load ratings by insert size:

Ø 6mm – Breaking load: 750 kg
Ø 8mm – Breaking load: 1,150 kg

Technical Specifications:

Base specifically engineered for the integration of Constrictor® textile inserts. This technical solution optimises the lead and control adjustment system onboard.

Technical Features:

Compatibility: Constrictor® textile inserts Ø6mm and Ø8mm
Optimised fastening: reduced number of fixing screws compared to standard bases, thereby decreasing:
- Overall system weight
- Deck drilling constraints
- Risk of water ingress


Ease of maintenance: insert removal and refitting simplified without full base disassembly
Control lead: passage drillings positioned at upper and lower sections for a straight-line run and rational load distribution

Applications:

Sheet leads, control lines, return arms, kicker/vang circuits.
Mounting: On deck, coaming, coachroof or bulkhead depending on rigging configuration.
